Inventis Triangle Audiometer

screening - air conduction with optional bone conduction

Inventis Triangle Audiometer

screening - air conduction with optional bone conduction

Code:
Manufacturer code
Brand:
Unit:
Availability:

1,969.01 £

(including VAT)

Price without VAT 1,613.94 £
info General information
assignment Technical information
work Standard equipment
list Compatible with
save_alt Downloads

General information

Triangle is a portable screening audiometer capable of performing air conduction tonal audiometry manually and automatically, with a frequency range from 125 Hz to 8kHz.

It is possible to enable the optional 'bone conduction' license at any time to conduct tonal audiometry via bone conduction and to enable masking signals.

Additionally, with the optional 'PC connectivity' license, it will be possible to transfer the exam results to the Maestro or Noah databases.

The color touch display makes Triangle intuitive and easy to use, thus optimizing daily clinical practice management.

Automatic tests
Automatic tonal audiometry can be performed by choosing from three different protocols:

  • Hughson-Westlake
  • Quick Search
  • Fixed Intensity

In addition to the Hughson-Westlake technique for determining the AC threshold, the user can select the Quick Search for threshold identification, which is based on the first response starting from the selected minimum level, or opt for the Fixed Intensity method, a basic screening test conducted at a fixed intensity level.

Portable system
Lightweight and compact, Triangle is extremely manageable and easily portable, thanks also to the provided soft case. Additionally, the rechargeable lithium-ion internal battery ensures more than 12 hours of continuous use, making Triangle the perfect choice for professionals on the go and for those requiring a reliable, simple, and fast screening solution.

Triangle is also equipped with internal memory that allows storage of exams for up to 100 patients. It will then be very simple to transfer all the data from the audiometer to the computer simply by connecting Triangle to the PC via USB cable (optional 'PC Connectivity' license to be activated upon request).

Standard equipment

  • DD45 supra-aural headphones
  • Patient response button
  • Medical power supply
  • USB cable
  • Audiogram sheets
  • User manual
  • Soft case




    Technical information

    Available signals
    • Pure tone, warble
    • Masking (optional, with 'Bone Conduction' license): NBN, WN
    Signal specifications
    • Attenuation step: 5 dB
    • Presentation: continuous, pulsed at 1 and 2 Hz
    • Warble: 5 Hz modulated sine wave
    Outputs and transducers
    • AC: DD45 or DD65 headphones, ER-3C insert earphones
    • BC: B71 bone vibrator
    Maximum signal intensity
    • Pure tone:
      - AC 100 dB HL
      - BC 60 dB HL
    Patient-operator communication
    • Talk-over microphone input
    • Patient response button
    Available tests
    • Manual tone audiometry
    • Automatic tone audiometry (available algorithms: Hughson-Westlake, Quick Search, Fixed Intensity)
    Connectivity
    • USB connection without drivers (optional)
    • Compatible software: Maestro
    Display
    • Type: Graphic Color LCD TFT, with capacitive touchscreen
    • Size: diagonal 2.8”, 43.2 mm × 57.6 mm
    • Resolution: 240 × 320
    Power Supply
    • Rechargeable internal Lithium-Ion battery
    • Battery life: more than 12 hours of continuous use
    • Main unit: 5 Vdc, 1.4 A
    • Dedicated external USB power supply: 100-240 Vac, 50/60 Hz, 0.3-0.15 A, compliant with IEC 60601-1
    Mechanical
    • Dimensions (LxWxH): 21 × 16 × 4 cm
    • Weight: 425 g
    Standards
    • Tonal audiometry: IEC 60645-1, ANSI S3.6
    • Calibration: ISO 389-1 (DD45), ISO 389-2 (ER-3C), ISO 389-3 (B71)
    • Electrical safety: IEC 60601-1, Class II type B
    • EMC: IEC 60601-1-2
    CE Certificate
    • MDR 2017/745/EU classification: Class IIa
    • Classification rule (Annex VIII, 2017/745): 10
    • Notified body: TÜV SÜD Product Service GmbH (0123)
